2006 picanol OmniPlus800-F-4-R-280

PICANOL air jet weaving looms type OmniPlus800-F-4-R-280 year of construction 07/2006, serial numbers 284189 / 284190, working width 2800mm, 4 colours, with jacquard STAUBLI type CX880 serial numbers W01/821XA/1M02 + W01/821XA/1M01 year of construction 08/2001, format 1408, 1344 hooks installed. Equipped with : SUMO, ELO, ETU, PRA, 4 weft colours, 4 weft feeders PICANOL type 1131X2 with PFL, feeder stand, bobbin creel with end bobbin detection, double warp tension rolls Ø 140mm with springs RHS + LHS, single pressure roll, Leno RHS + LHS, STAUBLI harness year of construction 2018, warp beam position 13, warp detection GROB with 6 detection bars, droppers, melt cutters RHS+LHS, touchscreen, walking step, waste-system, cardan axe, controller STAUBLI JC7 (year of construction 2016), 176 modules MP (=M6), single gantry, warp beam T280 with flanges 1000mm, foreseen for external batching motion but without external batching motion, speed 750 TPM.
